FANUC A16B-2202-0661 is an internal wiring board for Alpha-series regenerative power supply modules. FANUC documents it for PSM-5.5 and PSM-11 units in the A06B-6077 series, where it serves as the base wiring assembly used with the appropriate plug-in control PCB.
This is not a standalone servo amplifier control board. Confirm the A16B number, revision, host PSM model and paired control PCB before ordering.
A16B-2202-0661 Product Information
| Brand | FANUC |
| Model / MPN | A16B-2202-0661 |
| Series | FANUC Alpha power supply module series |
| Product Type | PSM wiring board / internal base PCB |
| Documented Host Module | A06B-6077-H106 PSM-5.5, revision B or later |
| Additional Host Module | A06B-6077-H111 PSM-11, revision B or later |
| Associated Unit Specs | A06B-6077-C106 and A06B-6077-C111 |
| Standard Control PCB | A16B-2202-0420, revision 05D or later |
| #BM Control PCB | A16B-2202-0423 |
| Revision Warning | Revision-A PSM units use different wiring-board specifications |
| Status | Discontinued by manufacturer; stock subject to availability |
| Condition | New, refurbished, or used 90% new; subject to stock |
| Testing | 100% tested before shipping; test video available |
| Handling | Normally 1–2 business days |
| Shipping / ETA | DHL, UPS, or FedEx worldwide; typically 3–7 business days |
| Warranty | 1 year for new/refurbished; 3 months for used 90% new |
| Service / Packing | Free technical support; anti-static reinforced packing |
Alpha PSM Internal Wiring Platform
A16B-2202-0661 is the internal wiring platform in compatible 200V-class regenerative Alpha PSM assemblies. The PSM supplies the common DC link for connected servo and spindle amplifiers, while the separate A16B-2202-0420 or 0423 board performs the applicable control functions.
PSM Model and Revision Compatibility
Compatibility depends on the complete power-supply model and hardware revision. FANUC documents this board with revision-B-or-later A06B-6077-H106 and A06B-6077-H111 units. Revision-A PSM-5.5 and PSM-11 assemblies use A16B-2202-0460 and A16B-2202-0461 respectively, so visual similarity does not establish interchangeability.
Testing and Installation Notes
REACO CNC checks the board number, revision, connectors, terminals, solder joints, insulation condition and operation in a compatible PSM setup as applicable. Installation must be completed by qualified personnel after isolating input power and confirming that the DC-link charge indicator is off.
Related resources: FANUC circuit boards, FANUC power supply modules and FANUC PCB and drive repair services.
