The FANUC A16B-2203-0695 is an internal wiring/power PCB for compatible two-axis FANUC αiSV20/20 servo amplifier modules. FANUC documentation assigns it to the 200V-class A06B-6114-H205 and A06B-6117-H205 configurations.
This A16B board is a replacement component rather than a complete servo amplifier. Confirm the full PCB number, revision, A06B amplifier nameplate, connectors and component layout before ordering because visually similar αiSV boards support different axis and current combinations.
A16B-2203-0695 Product Information
| Brand | FANUC |
| Model / MPN | A16B-2203-0695 |
| Board Type | Servo amplifier wiring / power PCB |
| Servo Series | FANUC αi Servo |
| Amplifier Model | αiSV20/20 / SVM2-20/20i |
| Axis Configuration | Two axes: L and M |
| System Voltage Class | 200VAC-input class |
| Compatible Amplifiers | A06B-6114-H205 and A06B-6117-H205 |
| Unit Specifications | A06B-6114-C205 and A06B-6117-C205 |
| Rated Output Current | 6.5 Arms per axis |
| Nominal Current Limit | 20 Apeak per axis |
| Associated Control PCB | A20B-2101-0041; older specification A20B-2100-0741 |
| Condition | New, refurbished, or used 90% new; subject to stock |
| Testing | 100% tested before shipping; test video available |
| Handling | Normally 1–3 business days |
| Shipping / ETA | DHL, UPS, or FedEx worldwide; typically 3–7 business days |
| Warranty | 1 year for new/refurbished; 3 months for used 90% new |
| Service / Packing | Free technical support; anti-static reinforced packing |
αiSV20/20 Dual-Axis Function
Inside the complete amplifier, the A16B-2203-0695 provides power-stage wiring, terminal connections and distribution for the L and M servo axes. The amplifier uses sine-wave PWM control with an IGBT bridge and communicates with a compatible FANUC CNC through the FSSB servo interface. Each axis is rated at 6.5 Arms with a nominal 20 Apeak current limit.
Compatibility and Board Differences
Do not select a board only by connector position or housing size. A16B-2203-0692 is used for αiSV4/4, A16B-2203-0694 for αiSV4/20 and A16B-2203-0670 for αiSV20/40. The 400V αiSV20/20HV uses A16B-2203-0810, while the level-up αiSV20/20L uses A16B-2203-0677.
Testing and Installation
REACO CNC checks the label, PCB condition, terminals, capacitors, connectors, power devices, insulation and amplifier operation on a compatible test platform where available. Isolate all power and allow the DC link to discharge completely before service. Installation should be completed by qualified CNC personnel.
