The FANUC A16B-2203-0870 is a power PCB for Alpha i Series αiSP22 spindle amplifier modules. It is used in selected 200VAC-class spindle drives and forms part of the main power stage that controls current supplied to the CNC spindle motor.

FANUC tables associate this board with A06B-6141-H022 Type A and A06B-6142-H022 Type B modules. Common PCB revisions include /02B and /03C; match the complete PCB number, amplifier suffix and control-board configuration before replacement.

A16B-2203-0870 Product Information

αiSP22 Power-Stage Function

A16B-2203-0870 interfaces with the control section and IGBT power device to support spindle acceleration, speed regulation and braking. A damaged board may contribute to overcurrent, power-stage or spindle-output alarms, but the IGBT, control PCB, motor and cables must also be diagnosed.

Type A, Type B and Older Modules

The Type A and Type B αiSP22 modules use the same A16B-2203-0870 power PCB but different control PCBs. Do not assume compatibility with older A06B-6111-H022 or A06B-6112-H022 modules, which FANUC documents with A16B-2203-0620. Confirm the full A06B number, # suffix, PCB revision, connectors and feedback configuration.

Testing and Installation Notes

REACO CNC checks the label, revision, connectors, power components, solder joints and applicable electrical functions. Qualified personnel must isolate power, verify DC-bus discharge and record all wiring before replacement. Back up spindle and CNC parameters before servicing the amplifier.
