Name: FCU8-KB046 / FCU8-DX750 Keyboard I/O Unit
Brand: MITSUBISHI
Price: 578.0 USD
Availability: InStock

FCU8-KB046 / FCU8-DX750 Mitsubishi 10.4-type CNC keyboard and operation panel I/O assembly

FCU8-KB046 / FCU8-DX750 Keyboard I/O Unit

Mitsubishi FCU8-KB046 / FCU8-DX750 10.4-Inch CNC Keyboard & I/O Unit

In stock

$578.00 USD

Shipping:

Delivery: Estimated 2- 6 business days delivery. See details

Returns: 14 days returns. See details

All parts are covered by REACO CNC warranty

All parts tested under load

Fast response, global shipping, expedited shipping available

Free technical support

More than 100,000 parts in stock & ready for delivery

Mitsubishi FCU8-KB046 / FCU8-DX750 10.4-Inch CNC Keyboard & I/O Unit

Brand	Mitsubishi Electric
Models	FCU8-KB046 keyboard + FCU8-DX750 operation panel I/O unit
Condition	New / Refurbished / Used options subject to current inventory
Handling Time	Within 1–2 working days for stocked units
Shipping	DHL / UPS / FedEx
Estimated Delivery Time (via DHL)	Asia: 1–3 business days Europe: 2–4 business days North America: 2–4 business days South America: 3–6 business days Middle East & Africa: 3–6 business days Oceania: 2–5 business days
Warranty	New / Refurbished: 1 year Used (90% new): 3 months
Category	CNC Keyboard and Operation Panel I/O Unit Set
Parameter Description	FCU8-KB046: Clear-key keyboard for a 10.4-type display unit, ONG (XYZ) layout FCU8-DX750: 96-point 24V/0V common DI, 64-point source DO rated at 200mA per point, and 3-channel MPG input
Interfaces	Control unit I/F, keyboard unit I/F and Remote I/O 2.0 I/F
Dimensions and Mass	FCU8-KB046: 140 × 220mm front outline; approximately 0.8kg FCU8-DX750: 116 × 179mm front outline; approximately 0.4kg
System Reference	Documented in Mitsubishi M800S / M80 and M800V / M80V CNC configurations; confirm the installed control and display units
Service	Functional testing and test video before delivery
Packing	Protective carton packaging

10.4-Inch CNC Keyboard and I/O Assembly

Mitsubishi FCU8-KB046 is a clear-key keyboard for a 10.4-type CNC display unit, while FCU8-DX750 is the operation panel I/O unit installed behind the keyboard in supported Mitsubishi CNC panel configurations. The two units perform different functions, so both complete model labels should be checked when replacing the assembly.

FCU8-KB046 ONG (XYZ) Clear-Key Layout

Mitsubishi documentation identifies FCU8-KB046 with an ONG (XYZ) key layout for M and L systems. It should not be confused with FCU8-KB041, which uses an ONG (XZF) layout for L systems, or FCU8-KB047, which has a full-keyboard arrangement.

FCU8-DX750 Verified 96DI/64DO Configuration

The FCU8-DX750 provides 96 digital inputs with selectable 24V/0V common wiring and 64 source-type digital outputs rated at 200mA per point. It also supports three manual pulse generator channels and includes control-unit, keyboard-unit and Remote I/O 2.0 interfaces.

Difference Between FCU8-DX750, DX760 and DX761

FCU8-DX750 has 96 inputs and 64 source outputs. FCU8-DX760 increases the output capacity to 96 points, while FCU8-DX761 retains the 96DI/64DO configuration and adds one analog input and one analog output. Similar appearance does not confirm identical I/O capacity or system compatibility.

Compatibility Checks Before Ordering

Confirm the FCU8-KB046 and FCU8-DX750 labels, 10.4-type display, ONG (XYZ) legends, CNC control-unit model, source-output requirement, DI/DO capacity, MPG channels, G402 keyboard cable, Remote I/O connection and rear mounting arrangement.

Send REACO CNC clear photos of the keyboard face, rear model labels, DX750 connectors and complete Mitsubishi CNC panel. The visible configuration can be reviewed before condition, stock, price and lead time are confirmed.

Mitsubishi CNC Parts and Repair Support

Browse related Mitsubishi CNC control systems and Mitsubishi CNC PCBs and I/O units. Related keyboards and I/O units should be compared by complete model number, key layout, output type and connector configuration.

For a faulty keyboard or I/O unit, REACO CNC also provides professional Mitsubishi CNC parts repair, including fault inspection, component-level repair and functional testing.
