Name: FANUC A06B-6321-H311 βiSVSP 20/20/40-7.5-B Amplifier
Brand: FANUC
Price: 5789.0 USD
Availability: OutOfStock

FANUC A06B-6321-H311 βiSVSP 20/20/40-7.5-B Amplifier

Disponibile

• Testing Video Provided

$3,970.00 USD

Spedizione:

Consegna: Consegna stimata in 2-6 giorni lavorativi. Vedi dettagli

Resi: 14 giorni per i resi. Vedi dettagli

Tutte le parti sono coperte dalla garanzia REACO CNC

Tutte le parti sono state testate sotto carico

Risposta rapida, spedizione globale, spedizione rapida disponibile

Supporto tecnico gratuito

Oltre 100.000 pezzi in magazzino e pronti per la consegna

FANUC A06B-6321-H311 is a βiSVSP 20/20/40-7.5-B servo/spindle amplifier for 200V-class CNC systems. The 180mm unit combines a regenerative power supply, three servo-axis channels and one spindle channel.

The 20/20/40 designation identifies the L, M and N servo peak-current classes. Rated output is 6.5 Arms for L/M and 13 Arms for N; spindle output is 35 Arms with HRV1 or 32 Arms with HRV2. It is also searched as A06B6321H311.

A06B-6321-H311 Product Specifications

Brand	FANUC
Model / MPN	A06B-6321-H311
Series / Model	βi-B / βiSVSP 20/20/40-7.5-B
Product Type	Power supply with three-axis servo and spindle amplifier
Main Input	Three-phase 200–240VAC, +10%/−15%, 47–63Hz; 33 Arms at 50Hz
Power-Supply Rating	12kVA; regenerative control
Common Supply Output	7.5kW continuous; 11kW/30 minutes; 27kW maximum
Control Power	24VDC ±10%; 2.7A maximum
L / M Servo Axes	6.5 Arms rated per axis; 20 Apeak limit
N Servo Axis	13 Arms rated; 40 Apeak limit
Spindle Output	35 Arms HRV1; 32 Arms HRV2
Control Method	Sine-wave PWM with IGBT bridge
Dimensions / Mass	380 × 180 × 264.5mm maximum / 8.8kg
AC Reactor	A81L-0001-0184
Condition	New, refurbished, or used 90% new; subject to stock
Handling	Normally 1–3 business days
Shipping / ETA	DHL, UPS, or FedEx worldwide; typically 2–6 business days
Warranty	1 year new/refurbished; 3 months used
Service / Packing	Tested with video, technical support and protective packing

Integrated Servo and Spindle Control

A06B-6321-H311 supplies and controls three feed axes plus one spindle. FANUC documents the platform for 30i, 31i, 32i and 35i-B systems and 0i-F systems. Actual motor compatibility depends on the machine configuration and parameters.

Replacement Compatibility

Confirm the full A06B-6321-H311 nameplate, 180mm width, input supply, L/M/N motors, spindle motor, feedback devices, connectors, CNC software and parameters. Do not substitute A06B-6320-H311, A06B-6321-H312 or A06B-6321-H332 based on appearance.

Testing and Installation Notes

REACO CNC checks the label, housing, fans, connectors, regenerative circuit, power stages, communication, alarms and servo/spindle channels as applicable. Back up all parameters before replacement. Qualified personnel must isolate power and confirm complete DC-bus discharge before installation.
